Description
|
SH4000 – HESS |
|
|
|
|
|
Product Characteristics |
|
|
Specification |
|
|
Model No. |
SH4000 |
|
Product Warranty |
5 Years |
|
Configuration |
All-in-one |
|
Configuration |
LFP (LiFePO4) |
|
Parts |
inverter |
|
Mounting Options |
Rack |
|
Max Parallel Units |
4 |
|
Battery Datasheet |
|
|
Electrical Data |
|
|
Nominal Voltage |
51.2 V |
|
Operating Voltage Range |
40 – 60 V |
|
Nominal Capacity |
100Ah@1hr |
|
Nominal Energy |
5.12 kWh |
|
Usable Energy |
5.12 kWh |
|
Nominal Discharge Current |
90 A |
|
Nominal Charge Current |
65 A |
|
Max. Discharge Current |
100 A |
|
Max. Charge Current |
100 A |
|
Internal Resistance |
5 mΩ |
|
Design Life |
5 Years |
|
Cycle Life |
4000@80%DOD |
|
Round Trip Efficiency |
0.99 % |
|
Temperature Parameters |
|
|
Charge Temperature |
-0 ~ +40 ℃ |
|
General Data |
|
|
Dimension (L/W/H) |
510x673x266 mm |
|
Weight |
65 Kg |
|
IP Rating |
IP54 |
|
Cooling Method |
Natural |
